111
> Change from previous revision
1
2
2
3 (SOL 1)
3 (SOL 2)
3 (SOL 13)
3 (SOL 14)
3 (SOL 15)
3 (SOL 16)
4
5
6
6
7
8
LIGHTWEIGHT FAIRWAY MOWER
57.1 Rear Reel Valve
7 Gang Option, Part Number 4195082
Serial No. All
Item Part No. Qty. Description Serial Numbers/Notes
1
N/S 1 Body
2 4136814 6 Nut, D03 Coil
3 4135552 6 Coil, D03 Solenoid
REFERENCE SOL1, SOL2, SOL13, SOL14,
SOL15, SOL16, See 62.1
4 4136815 3 Valve, D03 Solenoid
339909 4 • O-RIng
5 5003080 3 Valve, Flow Control
5003579 1 • Seal Kit
6 5001065 2 Plug, -6 ORB Port
7 4105980 3 Knob, Flow Control
8 4143527 12 Bolt, D03 Service Short
To Next Page
