108
> Change from previous revision
1
2
3
4 (SOL3)
4 (SOL4)
5
5
5
6
6
7
8
LIGHTWEIGHT FAIRWAY MOWER
55.1 Lift Valve
5 Gang Option, Part Number 4195081
Serial No. All
Item Part No. Qty. Description Serial Numbers/Notes
1
5003144 1 Relief Valve
5003579 1 • Relief Valve Seal Kit
2 5001355 3 Pilot Operated Check Valve
5003578 1 • Check Valve Seal Kit
3 4136815 1 Solenoid Valve
339909 4 • O-Ring
4 4135552 2 Coil REFERENCE SOL3, SOL4, See 62.1
5 5002157 4 Plug, Port
6 4136814 2 Nut, Coil, with “O”-Ring
7 4154700 3 Pilot Piston
8 4143527 4 Bolt, D03 Service Short
To Next Page
