LIGHTWEIGHT FAIRWAY MOWER
Item Part No. Qty. Description Serial Numbers/Notes
1
4247310 1 Seat Pan
2 4217621 1 Support, Seat
3 4210561 1 Adjuster, Double Latching
4 4132314 1 • Adjuster, Left Side
5 4132315 1 • Adjuster, Right Side
6 4210580 1 • Handle, Adjuster
7 450377 2 • Nut, M6-1 Nylock Hex
8 4268426 2 Support, Seat
9 409812 4 Screw, 5/16-18 x 3/4” Thread Cutting
> 10 4280951 1 Suspension Seat Assembly
11 4139436 1 • Arm Rest Kit R.H. Arm Rest in kit is not used.
12 4139450 1 • Switch, Seat REFERENCE SW6, See 62.1
13 5003769 1 Seat Switch Harness
14 3003928 1 Pouch, Literature
15 800943 2 TScrew, #10-16 x 3/4” Plastic
16 452004 2 Flat Washer, 1/4
17 403751J 8 Screw, 5/16-18 X 3/4” Serr Washer
18 831053 4 Spacer, Seat
19 4222229 1 Plug, 2 x 2” Tube
20 445795 15 Nut, 5/16-18 Spiralock Flange
21 REF 1 Armrest Assembly See 6.1
22 4332066 1 Support, Upper Armrest
23 4189843 4 Screw, M6-1 x 65 mm Hex Head
24 4188484 4 Flange, M6 Body Fastener
25 473211 4 Spacer, Black Neoprene
26 4209240 1 Pivot, Lower Armrest Support
27 450193 1 Screw, M8-1.25 x 20 mm Hex Head
28 450411 1 Lockwasher, M8
29 4188569 1 Plunger, Round Nose
30 471216 1 Grease Fitting, 1/4-28 Straight
31 441687 3 Carriage Bolt, 5/16-18 x 3”
32 450334 1 Nut, M16-2 Hex
To Next Page
