LIGHTWEIGHT FAIRWAY MOWER
Item Part No. Qty. Description Serial Numbers/Notes
1
N/S 1 Pump Housing
2 N/S 1 Charge Pressure Filtration Plate
● 3 N/S 1 Seal Adapter
4 N/S 3 Screw, 5/16 x 1” Hex Head Torque to 22 ft. lb. (30 Nm)
5 N/S 1 Plug, 7/8-14 (ORB-10)
6 339899 1 O-Ring, -10 ORB
7 N/S 1 Plug, 9/16-18 (-6 ORB) Torque to 27 ft. lb. (37 Nm)
8 339897 1 • O-Ring, -6 ORB
9 4134590 1 Charge Relief Valve
10 4134589 1 Charge Relief Spring
11 4134588 1 Shim Kit
12 N/S 1 Plug, Charge Relief Valve 3/4-16 Torque to 80 ft. lb. (80 Nm)
● 13 4224121 1 • O-Ring, -8 ORB
14 5003434 1 Relief Valve, 3625 psi
15 N/S 1 • Plug, Relief Valve 1-1/16-12 Torque to 130 ft. lb. (176 Nm)
● 16 339900 1 • O-Ring, -12 ORB
17 N/S 1 • Spring
18 N/S 1 Plug
19 N/S 1 • O-Ring
20 N/S 1 Plug, 1-1/16-12 Hex Socket Torque to 85 ft. lb. (115 Nm)
21 339900 1 • O-Ring, -12 ORB
22 4134612 1 Bypass Valve Torque to 15 ft. lb. (20 Nm)
● 23 N/S 1 • Backup Ring
● 24 N/S 1 • O-Ring
25 4134668 1 Plug, 7/16-20 (-4 ORB) Torque to 15 ft. lb. (20 Nm)
26 339896 1 O-Ring, -4 ORB
27 N/S 1 Cover, Gerotor
● 28 NS 1 O-Ring
● 29 NS 1 Temper Load Ring
30 N/S 1 Flange, Rear Mounting
● 31 362743 1 O-Ring Seal
32 N/S 3 Screw, 3/8 x 1” Hex Head Torque to 32 ft. lb. (43 Nm)
33 5003434 1 Relief Valve, 3625 psi
34 N/S 1 • Plug, Relief Valve 1-1/16-12 Torque to 130 ft. lb. (176 Nm)
● 35 339900 1 • O-Ring, -12 ORB
36 N/S 1 • Spring
● 5003034 1 Seal Kit Includes Items marked ●
