117
> Change from previous revision
LIGHTWEIGHT FAIRWAY MOWER
Item Part No. Qty. Description Serial Numbers/Notes
1
N/S 1 Flange, Front Mounting
2 N/S 1 Screw, 3/8 x 1-1/8 T50 Torx Torque to 43 ft. lb. (58 Nm)
3 4286054 6 Screw, 7/16 x 1” T55 Torx Torque to 67 ft. lb. (91 Nm)
● 4 N/S 1 Gasket, Front Flange
5 N/S 1 Bushing
6N/S2Pin
7 4134608 2 Journal Bearing
8N/S1Plate
9 4134597 1 Variable Swashplate
10 N/S 1 • Pin
11 4134606 1 • Pin
12 4134609 1 Shaft, Pump
13 4134610 1 Valve Plate
14 4134607 1 Pin, Alignment
15 4134592 1 Needle Bearing
16 4134614 1 Cylinder Block Kit
17 N/S 7 • Piston
18 N/S 1 • Slipper Plate
19 N/S 1 • Pivot
20 N/S 1 • Spring, Pin Retaining
21 N/S 3 • Pin
22 N/S 1 • Cylinder Block
23 N/S 1 • Bushing, Front Spring
24 N/S 1 • Spring
25 N/S 1 • Bushing, Rear Spring
26 N/S 1 • Ring, Retaining
27 N/S 1 Retaining Ring, Internal
28 4286053 1 Roller Bearing
29 4134595 2 Retaining Ring
30 5003433 1 Shaft Seal
31 N/S 1 Cover, Neutral Adjust Servo
32 N/S 1 Cover, Servo
● 33 N/S 1 Gasket, Servo Cover
34 N/S 10 Screw, 1/4 x 1-1/8” Hex Flange Torque to 11 ft. lb. (15 Nm)
35 N/S 2 Plug, Orifice
● 36 4134618 1 Piston Ring Kit
● 37 N/S 2 Bearing
38 N/S 1 Piston, Servo
39 N/S 1 Screw, Servo Neutral Adjustment
40 N/S 1 Guide, Spring
41 N/S 1 Stop, Servo
● 5003034 1 Seal Kit Includes Items marked ●
Parts List continued on next page.
