Jacobsen LF557 4WD - Page 13

13
> Change from previous revision
LIGHTWEIGHT FAIRWAY MOWER
Item Part No. Qty. Description Serial Numbers/Notes
1
4247310 1 Seat Pan
> 2 4336570 1 Support, Seat
> 3 4346127 1 Pivot, Lower Armrest Support
4 450193 1 Screw, M8-1.25 x 20 mm Hex Head
5 450411 1 Lockwasher, M8
6 4188569 1 Plunger, Round Nose
7 471216 1 Grease Fitting, 1/4-28 Straight
8 548804 4 Nut, 3/8-16 Hex Flange
9 400258 4 Screw, 3/8-16 x 3/4” Hex Head
10 4313306 1 Suspension Seat Assembly
4297937 • Seat Switch
> 11 400216J 2 Screw, 5/16-18 x 2-3/4” Hex Head
12 450334 1 Nut, M16-2 Hex
13 4332066 1 Support, Upper Armrest
14 4189843 4 Screw, M6-1 x 65 mm Hex Head
15 4188484 4 Flange, M6 Body Fastener
16 473211 4 Spacer, Black Neoprene
17 403751J 4 Screw, 5/16-18 X 3/4” Serr Washer
> 18 REF 1 Armrest Assembly See 6.1
19 445795 15 Nut, 5/16-18 Spiralock Flange
