LIGHTWEIGHT FAIRWAY MOWER
Item Part No. Qty. Description Serial Numbers/Notes
1
4284894 1 Armrest, Upper
2 4284892 1 Armrest, Lower
3 4189540 8 Screw, M4-0.7 x 20 mm Torx
4 4188480 8 Flange, M4 x 4 mm Body
5 4329452 1 Harness, LDU T4I Engine Options
5 4301099 1 Harness, LDU T4F/Stage 5 Engine Options
6 843942 1 • Socket, 12V Accessory Plug REFERENCE SW8, See 62.1
7 N/S 2 ••Screw
8 4150539 1 Horn REFERENCE U20, See 62.1
9 N/S 1 • Ring Nut
10 4188482 8 Spacer, Black Neoprene
11 4283269 1 Key Switch REFERENCE SW8, See 62.1
12 4283654 1 • Key
13 4283653 1 • Nut, M22-1.5 Switch Backing
14 4283652 1 • Nut, M22-1.5 Switch Face
15 4283276 1 Plate, Switch
16 4323427 1 Joystick, 5 Gang Mower REFERENCE SW11, See 62.1
16 4323428 1 Joystick, 7 Gang Mower REFERENCE SW11, See 62.1
17 4189841 6 Flat Washer, 4 mm Stainless Steel
18 450408 2 Lockwasher, 4 mm
19 450321 2 Nut, M4-0.7 Hex
20 4189840 2 Screw, M4-0.7 x 20 mm Pan Head Stainless Steel
21 4343926 1 Switch, Mow REFERENCE SW10, See 62.1
22 4130133 1 Rocker Switch, Momentary REFERENCE SW9, See 62.1
23 4130132 3 Rocker Switch REFERENCE SW12-14, See 62.1
24 4316206 1 LDU Controller REFERENCE U21, See 62.1
25 4188840 1 Visor, Armrest
26 409952 4 Screw, M4 x 13 mm Thread Cutting Stainless Steel
27 4168564 1 Hinge, Armrest
28 4201880 4 Screw, #6-32 x 1/2” Flat Head
29 444304 4 Nut, #6-32 Hex
30 4168562 1 Door, Armrest
31 4201867 4 Screw, #6-32 x 3/8” Thread Cutting Stainless Steel
32 4156925 1 Lanyard
33 4201980 4 Screw, #4 x 1/2” Self Threading
34 4168563 1 Set, Magnetic Catch
35 4189842 7 Spacer
36 4200540 2 Adhesive Mount, Cable Tie
37 402006 1 Screw, #6-32 x 1/2” Slotted Head
38 473142 2 Cable Tie
39 4225220 1 Panel, Plug T4I Engine Options
39 4326362 1 Switch, Adaptive Throttle Rotary T4F/Stage 5 Engine SW3, See 62.1
40 4244950 1 Shim, LDU Retaining
41 819195 1 Screw, #8-18 x 1/2” Self Drilling
42 450387 2 Flat Washer, M4
