Jacobsen LF557 4WD - Page 17

17
> Change from previous revision
LIGHTWEIGHT FAIRWAY MOWER
Item Part No. Qty. Description Serial Numbers/Notes
1
4282078 1 Pedal, Traction REFERENCE U5, See 62.1
2 400128 4 Screw, 1/4-20 x 3-1/2” Hex Head
3 446130 4 Lockwasher, 1/4 Heavy
4 453023 4 Flat Washer, 1/4
5 4233220 4 Spacer
6 4235560 1 Plate, Pedal Support
7 4297945 1 Mount, Arm
8 4284031 1 Insert, Anti-Rotation
9 450452 2 Nut, M6-1 Hex Flange
10 450134 1 Screw, M4-0.70 x 16 mm Hex Head
11 450419 1 Lockwasher, M4
12 450387 1 Flat Washer, M4
13 450321 1 Nut, M4-0.70 Hex
14 4225480 1 Plate, Pedal Pivot
15 450171 2 Screw, M6-1 x 20 mm Hex Head
16 450410 2 Lockwasher, M6
17 400410 2 Screw, 1/2-13 x 1-3/4” Hex Head Pedal Stops
18 443118 2 Nut, 1/2-13 Hex
19 4209121 1 Arm, Traction Pedal
20 400186 2 Screw, 5/16-18 x 7/8” Hex Head
21 445795 2 Nut, 5/16-18 Spiralock Flange
22 3003474 1 Grip, Pedal
23 3003475 1 Grip, Pedal
24 4234620 1 Tie Strap, Push-On
