LIGHTWEIGHT FAIRWAY MOWER
Item Part No. Qty. Description Serial Numbers/Notes
1
4329926 1 Frame
2 366871 2 • Bushing
3 366870 4 • Bushing
4 4329329 1 Front Axle
5 366870 6 • Bushing
6 4113047 6 Screw, 5/8-18 x 1-1/2” Hex Head Grade 8 Bolt
7 452016 12 Flat Washer, 5/8
8 4140094 6 Washer 11/16 x 1-5/16 x 5/32 Hard
9 443128 6 Nut, Hex 5/8-18 UNF
10 4244422 1 Plug, 3” x 3” Tube
11 4265651 2 Wheel Motor
4274170 1 • Complete Seal Kit
4274171 1 • Brake Seal Kit
4274172 1 • Kit, Brake
4274173 1 • Kit, Brake Disc
4274174 1 • Bearing, Taper-In
4274175 1 • Bearing, Taper-Out
4274176 1 • Bearing Support Seal Kit
4274177 1 • Cam Ring
> 4370586 5 • M14-1.5 Wheel Studs
> 12 8008460 5 • Nut, M14-1.5 Spherical Wheel
> 13 64189-8A 16 Screw, 1/2-13 x 1-1/4” Hex Socket
14 446154 16 Lockwasher, 1/2 Heavy
15 445795 1 Nut, 5/16-18 Hex Flange
> 4251535 2 Wheel and Tire Assembly
16 4236060 1 • Tire, 26.5 x 14-12 4 Ply
17 4251534 1 • Rim, 12 x 10.5
18 360111 1 • Valve, Inflation
> 19 4329218 1 Battery Tray
20 358794 2 Washer, 3/8
21 445796 8 Nut, 3/8-16 Spiralock Flange
22 4312568 1 Clamp, Battery
23 400188 1 Screw, 5/16-18 x 1” Hex Head
24 446134 1 Lockwasher, 5/16
25 4330697 1 Mount, Controller
26 4330486 1 Cover, Controller See 2.1
> 27 4243204 1 Weight, Rear Bumper 2WD Units Only
> 28 441614 1 Carriage Bolt, 5/16-18 x 1” 2WD Units Only
To Next Page
