23
> Change from previous revision
LIGHTWEIGHT FAIRWAY MOWER
Item Part No. Qty. Description Serial Numbers/Notes
> 4236062 2 Rear Wheel and Tire Assembly
1
4236061 1 • Tire, 20 x 10-8 Treaded 4-Ply
2 4236021 1 • Rim
3 360111 1 • Inflation Valve
4 361648 6 Washer, Thrust
5 361647 2 Bearing, Thrust
6 471214 2 Fitting, Grease
7 461393 2 Pin, Spring 1/4 x 2”
8 4300293 1 Steering Axle
9 3010489 4 • Bushing
10 4271774 1 Cylinder, Steering
4276851 1 • Seal Kit
11 443840 2 Nut, 1-12 Hex Jam
> 12 400470 1 Flat Washer, 1 x 2-3/4 x 1/4
13 366789 1 Spacer, Axle
14 460064 1 Cotter Pin, 1/4 x 1-1/2”
15 460028 2 Cotter Pin, 1/8 x 1”
16 4141925 2 Ball Joint
17 400194 2 • Screw, 5/16-18 x 1-3/4”
18 444718 2 • Locknut, 5/16-18 Hex
19 471214 2 • Grease Fitting
20 445672 2 • Nut, 5/8-18 Slotted Hex
21 4121829 1 Ball Joint, Right Hand Thread
22 4121828 1 Ball Joint, Left Hand Thread
23 4121986 1 • Dust Cover
24 471214 1 • Grease Fitting
25 4124204 2 Nut, 9/16-18 Slotted Hex
26 322847 2 Clamp
27 400192 2 Screw, 5/16-18 x 1-1/2”
28 4300458 1 Tie Rod
29 460050 2 Cotter Pin, 3/16 x 1-1/4”
30 445710 2 Nut, 1-14 Slotted Hex
31 4329267 1 Spindle, Right
32 4329268 1 Spindle, Left
33 5002910 2 Wheel Hub
34 554329 2 • Seal, Grease
35 500596 2 • Bearing, Cup and Cone
36 545692 2 • Dust Cap
37 354807 8 • Wheel Nut
38 460032 2 Cotter Pin, 1/8 x 1-1/2”
39 471227 1 45° Grease Fitting
40 443106 2 Nut, 5/16-18 Hex
To Next Page
