33
> Change from previous revision
LIGHTWEIGHT FAIRWAY MOWER
Item Part No. Qty. Description Serial Numbers/Notes
1
4189940 1 Air Cleaner
2 4133818 1 • Cover, Air Cleaner
3 4133820 1 • Filter, Primary Air Cleaner
4 4133821 1 • Filter, Safety Air Cleaner
5 5003373 1 • Vactuator Valve
6 4128084 1 Bracket, Air Cleaner Mount
7 4304523 1 Bracket, Air Cleaner
8 400182 3 Screw, 5/16-18 x 5/8” Hex Head
9 445795 2 Nut, 5/16-18 Spiralock Flange
10 800709 2 Screw, 3/8-16 x 1” Hex Flange
11 452008 2 Flat Washer, 3/8
12 3002195 1 Elbow, 1/8 NPF 90°
13 365398 1 Indicator, Air Cleaner
14 472205 1 Plug, 3/8 NPT Socket Head
15 4120977 1 Hose, Shroud to Air Cleaner
16 337229 5 Clamp, Hose
17 4267512 1 Hose, Air Cleaner to MAF Sensor
18 4266170 1 Sensor, Mass Air-Flow (MAF) REFERENCE U17, See 62.1
19 4266931 1 Hose, MAF to Engine Intake
20 4312567 1 Bracket, MAF Support
21 445796 4 Nut, 3/8-16 Spiralock Flange
22 358794 4 Flat Washer, 3/8
23 REF 1 Radiator Assembly See 16.1
24 4301331 1 Bracket, Hose Clamp
25 441602 2 Carriage Bolt, 5/16-18 x 3/4”
26 548911 2 Nut, 5/16-18 Hex Flange
27 4181861 1 Decal, Start Assist Fluids
To Next Page
