35
> Change from previous revision
LIGHTWEIGHT FAIRWAY MOWER
Item Part No. Qty. Description Serial Numbers/Notes
1
4305137 1 Radiator / Hydraulic Oil Cooler
2 550863 1 • Radiator Cap
3 4301038 1 Shroud, Radiator Fan Includes Decal 4131663
4 400264 6 Screw, 3/8-16 x 1-1/4 Hex Head
5 446140 6 Lockwasher, 3/8
6 452008 6 Flat Washer, 3/8
7 4328086 1 Bracket, Fuel Pump
8 362535 1 Screw, M6-1 x 16 mm Hex Head
9 450323 1 Nut, M6-1 Hex
10 345666 1 Clamp, 1/2” Hose
11 4153197 1 Decal, Pressure Wash Warning
12 REF 1 Engine
13 4113986 1 • Engine Oil Filter
14 557367 1 • Recovery Tank
15 554748 1 Hose, Radiator Overflow, Bulk 10 Foot Length, Cut to 33”
16 345671 1 Clamp, 13/16” Hose
17 48540-01 2 Clamp, Hose
18 4301052 1 Hose, Lower Radiator
19 4301051 1 Hose, Upper Radiator
20 326112 4 Clamp, Hose
21 4266292 AR Seal, Trim 10 Foot Length, cut to 72”
> 22 450399 1 Flat Washer, M6
23 4308895 1 Deflector, Air Intake
24 800709 2 Screw, 3/8-16 x 1” Hex Flange
25 445796 2 Nut, 3/8-16 Spiralock Flange
26 4181862 1 Decal, Radiator Cap Warning
