41
> Change from previous revision
LIGHTWEIGHT FAIRWAY MOWER
Item Part No. Qty. Description Serial Numbers/Notes
1
4299955 1 Engine, Kubota D1803-M-DI-E3B
4113986 1 • Filter, Engine Oil
2 4268230 1 • Gasket, Exhaust
3 363586 4 Screw, M8-1.25 x 20 mm Hex Head
4 450411 4 Lockwasher, M8
5 4333292 1 Pipe, Flex
6 4271291 1 Mount, Left Rear Engine
7 4271292 1 Mount, Right Rear Engine
> 8 800546 13 Screw, M12-1.25 x 35 mm Hex Head
9 446154 13 Lockwasher, 1/2 Heavy
10 453017 13 Flat Washer, 1/2
11 362263 1 Screw, M10-1.25 x 25 mm Hex Head
12 363485 3 Lockwasher, M10
13 453013 1 Flat Washer, 7/16
> 14 4198040 4 Screw, M12-1.75 x 45 mm Flange
> 15 450455 4 Nut, M12-1.75 Hex Flange
16 4343048 4 Isolator, Cushy Float
17 4330089 1 Mount, Left Front Engine
18 4330093 1 Mount, Right Front Engine
19 4333607 1 Bracket, Oil Funnel
20 548905 8 Screw, 3/8-16 x 1” Hex Flange
21 548804 8 Nut, 3/-816 Whizlock Flange
22 4330009 1 Bracket, Exhaust Mount
23 4303771 1 Clamp, 2-1/4” Exhaust
24 4333291 1 Muffler
25 4330226 1 Bracket, Exhaust Mount
26 800385 8 Screw, 3/8-16 x 3/4” Hex Flange
27 445796 14 Nut, 3/8-16 Spiralock Flange
28 4384027 1 Fan, 8 Blade, 35°
29 452380 4 Screw, M6-1 x 30 mm Hex Flange
30 4333293 1 Exhaust Pipe
31 4330326 1 Bracket, Exhaust Adjustment
32 4330697 1 Mount, Controller See 8.1
33 800710 2 Screw, 5/16-18 x 1” Hex Flange
34 361064 2 P-Clip, 5/8”
35 4343206 2 Spring, Tail Pipe
36 4333287 1 Tail Pipe
37 162236 2 Clamp, 2-1/8” Exhaust
38 548911 2 Nut, 5/16-18 Hex Flange
39 364501 1 Sender, Temperature
40 345671 1 Clamp, 3/4”
To Next Page
