43
> Change from previous revision
LIGHTWEIGHT FAIRWAY MOWER
Item Part No. Qty. Description Serial Numbers/Notes
1
4299954 1 Engine, Kubota D1803-CR-E4B
4113986 1 • Filter, Engine Oil
2 4134436 1 • Gasket, Exhaust
3 5003269 2 • Screw, M6-1 x 20 mm Hex Flange
4 4297102 2 • Screw, M6-1 x 12 mm Hex Flange
5 4318343 1 Bracket, DPF Sensor
6 4271291 1 Mount, Left Rear Engine
7 4271292 1 Mount, Right Rear Engine
> 8 800546 13 Screw, M12-1.25 x 35 mm Hex Head
9 446154 13 Lockwasher, 1/2 Heavy
10 453017 13 Flat Washer, 1/2
11 362263 1 Screw, M10-1.25 x 25 mm Hex Head
12 363485 3 Lockwasher, M10
13 453013 1 Flat Washer, 7/16
> 14 4198040 4 Screw, M12-1.75 x 45 mm Flange
> 15 450455 4 Nut, M12-1.75 Hex Flange
16 4343048 4 Isolator, Cushy Float
17 4330089 1 Mount, Left Front Engine
18 4330093 1 Mount, Right Front Engine
19 4333607 1 Bracket, Oil Funnel
20 548905 8 Screw, 3/8-16 x 1” Hex Flange
21 548804 8 Nut, 3/-816 Whizlock Flange
22 4300792 1 Bracket, Exhaust Mount
23 366884 2 Screw, M10-1.25 x 20 mm Hex Head
24 450401 2 Flat Washer, M10
25 4304777 1 Bracket, Exhaust
26 440078 2 Carriage Bolt, 5/16-18 x 3/4”
27 548911 4 Nut, 5/16-18 Hex Flange
28 4384027 1 Fan, 8 Blade, 35°
29 452380 4 Screw, M6-1 x 30 mm Hex Flange
30 4333290 1 Exhaust Pipe
31 326112 2 Clamp
32 4299171 1 Sleeve, Insulating
33 363586 4 Screw, M8-1.25 x 20 mm Hex Head
34 450411 4 Lockwasher, M8
35 4343206 2 Spring, Tail Pipe
36 4333287 1 Tail Pipe
37 162236 1 Clamp, Exhaust
To Next Page
