LIGHTWEIGHT FAIRWAY MOWER
Item Part No. Qty. Description Serial Numbers/Notes
1
4237504 1 Tank, Fuel
2 3006243 2 Plate, Tank Mounting
3 403769 7 Screw, 1/4-20 x 1/2” Hex Flange
4 4333247 1 Plate, Blanking Top
5 4332048 3 Screw, #10-24 x 3/8” Thumb
6 4238043 1 Plate, Fuel Block Off
7 5003374 1 Gasket, Fuel
8 403910J 5 Screw, #10-24 x 1/2” Truss Head
9 446118 5 Lockwasher, #10 Heavy
10 4333246 1 Plate, Blanking
11 403908J 3 Screw, #10-24 x 3/8” Truss Head
12 4340626 1 Bracket, Fuel Tank Compartment
13 441624 2 Carriage Bolt, 3/8-16 x 1”
14 548804 6 Nut, 3/8-16 Whizlock Flange
15 361117 3 Bushing
16 2810702 1 Valve, Needle
17 132647 1 Valve, Fuel Shut-Off
18 554748 AR Hose, 5/16” ID Tank to Separator 10 Foot Length, Cut to 64”
19 48540-01 8 Hose Clamp, Worm Gear
20 4272290 1 Fuel Pump
21 400108 2 Screw, 1/4-20 x 3/4” Hex Head
22 445794 2 Nut, 1/4-20 Spiralock Flange
23 4329066 1 Bracket, Fuel Pump
24 800709 2 Screw, 3/8-16 x 1” Hex Flange
25 365976 2 Fitting, 1/8 NPT x 5/16 Hose Barb
26 554748 AR Hose, 5/16 ID Fuel Pump to Filter 10 Foot Length, Cut to 16”
27 REF 1 Tier 4 Final / Stage 5 Engine V2403 Shown, D1803 the Same
28 4138107 4 • Washer, Brass
29 4138103 2 • Bolt, M14-1.5 Banjo
30 2501172 2 • Fitting, Banjo Fuel
31 4280212 1 Water Separator
4297126 1 • • Element, Water Separator
32 4280171 1 • Fuel Filer Element
4297133 1 • • Cartridge, Filter
33 554748 1 Hose, 5/16 ID Fuel Filter to Engine 10 Foot Length, Cut to 13”
34 4328107 1 Bracket, Separator
35 554748 1 Hose, 5/16 ID Separator to Fuel Pump 10 Foot Length, Cut to 13”
36 554748 1 Hose, 5/16 ID Engine to Tank 10 Foot Length, Cut to 70”
37 3003704 1 Fitting, Fuel Overflow
38 473142 2 Cable Tie, 3/16 x 16”
39 345671 1 Clamp, 3/4” Hose
40 4328086 1 Bracket, Fuel Pump
41 800714 2 Screw, 3/8-16 x 1-1/4” Hex Flange
42 4305856 1 Cap, Diesel Fuel with Gauge Ultra Low Sulfur Only
