53
> Change from previous revision
LIGHTWEIGHT FAIRWAY MOWER
Item Part No. Qty. Description Serial Numbers/Notes
1
3005871 1 Tank, Hydraulic See 24.1
2 365959 1 Strainer, Tank
2812075 1 • O-Ring
3 340090 1 Fitting, 24-24 90°
339915 1 • O-Ring, -24 ORFS
339903 1 • O-Ring, -24 ORB
4 1003992 1 Tube, Gear Pump Suction
5 4148857 3 Hose, Tank
6 3008673 6 Clamp, Constant Torque Hose
7 3001296 2 Fitting, -12 ORB x 1” barbed Five Gang Mowers
339900 1 • O-Ring, -12 ORB
7 361689 2 Fitting, -16 ORB x 1” barbed Seven Gang Mowers
339901 1 • O-Ring, -16 ORB
8 REF 1 Pump Assembly See 21.1
9 339998 1 Fitting, 16-12 Straight
339913 1 • O-Ring, -16 ORFS
339900 1 • O-Ring, -12 ORB
10 4113601 1 Tube, Return Manifold
See 33.1 and 27.1 for connecting
tubes
339908 5 • O-Ring, -4 ORFS
11 361689 1 Fitting, -16 ORB x 1” barbed
339901 1 • O-Ring, -16 ORB
12 364190 1 Clamp, 1-1/2” Diameter Secure tube to frame.
13 400264 1 Screw, 3/8-16 x 1-1/4” Hex Head
14 445796 1 Nut, 3/8-16 Spiralock Flange
To Next Page
