Jacobsen LF557 4WD - Page 57

57
> Change from previous revision
LIGHTWEIGHT FAIRWAY MOWER
Item Part No. Qty. Description Serial Numbers/Notes
1
4300318 1 Pump, Four Section Gear See 21.1
5003173 1 • Seal Kit
2 339989 4 Fitting, -10 ORFS x -10 ORB Straight
339911 1 • O-Ring, -10 ORFS
339899 1 • O-Ring, -10 ORB
3 340377 1 Fitting, -10 ORFS 90° Swivel
339911 1 • O-Ring, -10 ORFS
4 4244263 1 Hose, Pump to Front Reel Valve Front Reel Valve Port P
5 339990 1 Fitting, -10 ORFS x -12 ORB Straight
339911 1 • O-Ring, -10 ORFS
339900 1 • O-Ring, -12 ORB
6 4355571 1 Valve, Front Reel See 24.1
7 340033 2 Fitting, -10 ORFS x -10 ORB 45°
339911 1 • O-Ring, -10 ORFS
339899 1 • O-Ring, -10 ORB
8 4328568 1 Hose, Pump to Rear Reel Valve Rear Reel Valve Port WP
9 4328569 1 Hose, Pump to Rear Reel Valve Rear Reel Valve Port CP
10 4195082 1 Valve, Rear Reel See 24.1
11 340274 1 Tee, -8 ORFS x -10 ORFS x -8 ORB
339910 1 • O-Ring, -8 ORFS
339911 1 • O-Ring, -10 ORFS
339898 1 • O-Ring, -8 ORB
12 364945 1 Fitting, -10 ORB Diagnostic
13 363030 1 Dust Cover
14 1003334 1 Hose, Pump to Steering Valve Steering Valve Port P
15 4212981 1 Valve, Steering See 12.1
16 1003339 1 Hose, Steering Valve to Lift Valve Steering Port E, Lift Valve Port P
17 339985 2 Fitting, -8 ORFS x -10 ORB Straight
339910 1 • O-Ring, -8 ORFS
339899 1 • O-Ring, -10 ORB
18 4325986 1 Tube, Return Filter
19 1003340 1 Hose, Steering Valve to Lift Valve Steering Port T, Lift Valve Port T2
20 4327476 1 Tube, Lift Valve Return Lift Valve Rear Port T1
21 340070 1 Fitting, -10 ORFS x -10 ORB 90°
339911 1 • O-Ring, -10 ORFS
339899 1 • O-Ring, -10 ORB
22 4326930 1 Tube, Front Reel Valve Return Front Reel Valve Port T
23 4326306 1 Tube, Rear Reel Valve Return Rear Reel Valve Port T1
24 339996 1 Fitting, -12 ORFS x -16 ORB Straight
339912 1 • O-Ring, -12 ORFS
339901 1 • O-Ring, -16 ORB
25 123015 1 Charge Filter See 24.1
26 4195083 1 Valve, Lift See 24.1
27 4327475 1 Tube, Rear Reel Valve Return Rear Reel Valve Port T2
