LIGHTWEIGHT FAIRWAY MOWER
Item Part No. Qty. Description Serial Numbers/Notes
1
4327630 1 Tube, Left 4WD Forward Traction See 29.1
2 4326933 1 Tube, Right 4WD Forward Traction 4WD Valve Port RF, See 29.1
3 339994 2 Fitting, -12 ORFS x -12 ORB Straight
339912 1 • O-Ring, -12 ORFS
339900 1 • O-Ring, -12 ORB
4 340034 4 Fitting, -10 ORFS x -12 ORB 45°
339911 1 • O-Ring, -10 ORFS
339900 1 • O-Ring, -12 ORB
5 4328426 1 Hose, 4WD Valve to Left Rear Motor
4WD Valve Port LRF
Left Motor Port A
6 4328426 1 Hose, 4WD Valve to Right Rear Motor
4WD Valve Port RRF
Right Motor Port B
7 340070 4 Fitting, -10 ORFS x -10 ORB 90°
339911 1 • O-Ring, -10 ORFS
339899 1 • O-Ring, -10 ORB
8 4328426 1 Hose, Right Rear Motor to 4WD Valve
4WD Valve Port RRR
Right Motor Port A
9 4328426 1 Hose, Left Rear Motor to 4WD Valve
4WD Valve Port LRR
Left Motor Port B
10 4333510 1 Valve, 4WD See 24.1
11 339999 1 Fitting, -16 ORFS x -16 ORB Straight
339913 1 • O-Ring, -16 ORFS
339901 1 • O-Ring, -16 ORB
12 4326934 1 Tube, 4WD Reverse Traction 4WD Valve Port REV, See 29.1
13 339979 2 Fitting, -6 ORFS x -6 ORB Straight
339909 1 • O-Ring, -6 ORFS
339897 1 • O-Ring, -6 ORB
14 4304283 1 Tube, 4WD Valve Drain 4WD Valve Port DRN
15 339920 1 Cap, -4 ORFS
16 4333906 1 Tube, 4WD Valve Pilot 4WD Valve Port M2, See 29.1
17 400366 1 Clamp, 1” Tube
18 4304279 1 Tube, Oil Cooler Return See 32.1
339908 2 • O-Ring, -4 ORFS
339909 1 • O-Ring, -6 ORFS
19 4322946 2 Motor, Rear Traction See 11.1
20 4310406 1 Tube, Left 4WD Traction 4WD Valve Port LF
21 4312569 1 Clamp, 13/16” Tube
22 445796 1 Nut, 3/8-16 Hex Flange
