67
> Change from previous revision
LIGHTWEIGHT FAIRWAY MOWER
Item Part No. Qty. Description Serial Numbers/Notes
1
4325986 1 Tube, Return Filter See 33.1 and 29.1 for connecting tubes
339912 1 • O-Ring, -12 ORFS
339913 1 • O-Ring, -16 ORFS
2 340077 3 Fitting, -16 ORFS x -16 ORB 90°
339913 1 • O-Ring, -16 ORFS
339901 1 • O-Ring, -16 ORB
3 132704 1 Filter, Return Hydraulic See 24.1
557772 1 • Filter Element
4 4304783 1 Hose, Return Filter to Oil Cooler
5 340039 1 Fitting, -16 ORFS x -16 ORB 45°
339913 1 • O-Ring, -16 ORFS
339901 1 • O-Ring, -16 ORB
6 4305137 1 Radiator/Hydraulic Oil Cooler
7 4327479 1 Tube, Oil Cooler Return
See 28.1, 29.1, 30.1, and 31.1 for
connecting tubes
339908 2 • O-Ring, -4 ORFS
339909 1 • O-Ring, -6 ORFS
8 4124647 1 Hose, Return Tube
9 3008673 2 Clamp, Constant Torque Hose
10 361689 1 Fitting, -16 ORB x 1” barbed
339901 1 • O-Ring, -16 ORB
11 3005871 1 Tank, Hydraulic See 24.1
To Next Page
