Jacobsen LF557 4WD - Page 7

7
> Change from previous revision
LIGHTWEIGHT FAIRWAY MOWER
Item Part No. Qty. Description Serial Numbers/Notes
1
4304316 1 Hood
2 4130360 AR • Seal, Trim 64” Length, cut to 52”
3 4196102 1 • Foam, Hood Mount
4 4187681 2 • Decal, Jacobsen
5 403770 2 Screw, 5/16-18 x 3/4” Hex Flange
6 4333407 2 Decal, LF550 550 Reel Mount Option
6 4333408 2 Decal, LF570 570 Reel Mount Option
6 4331096 2 Decal, LF557 557 Reel Mount Option
6 4331099 2 Decal, LF577 577 Reel Mount Option
7 4138359 AR Foam, Sealing Cut four 5-1/2” pieces
8 4221420 1 Seal, Left Side Air
9 4221421 1 Seal, Right Side Air
10 800794 6 Screw, 5/16-18 x 3/4 Hex Flange
11 800907 4 Nut, 5/16-18 Hex Flange
12 4330486 1 Cover, Controller See 8.1
13 445796 2 Nut, 3/8-16 Spiralock Flange
14 4330694 2 Panel, Controller Access
15 548458 2 Clevis Pin, 1/2 x 1-1/4”
16 822529 2 Hair Pin, 1/8 x 7/16 x 2”
17 453017 2 Flat Washer, 1/2
18 4111408 1 Decal, Bio Fluid
> 19 4357766 1 Shroud, Rear Frame
20 445640 2 Nut, 3/8-16 Steel Wing
> 21 3006233 2 Washer, 3/8
22 4291711 AR Seal, Bulk 72” Length, Cut two 2-1/4” and two 25”
23 4291172 1 Latch, Over Center
24 800017 2 Screw, 1/4-20 x 1” Pan Head
25 800026 2 Screw, 1/4-20 x 3/4” Pan Head
26 453023 4 Flat Washer, 1/4
27 446130 4 Lockwasher, 1/4 Heavy
28 443102 4 Nut, 1/4-20 Hex
29 4298793 1 Backer, Hood Latch
30 4331105 1 Decal, 4WD 4WD Option
31 4282178 2 Shield, Adhesive Heat
