LIGHTWEIGHT FAIRWAY MOWER
Item Part No. Qty. Description Serial Numbers/Notes
1
4355571 1 Valve, Reel See 24.1
2 339989 2 Fitting, -10 ORFS x -10 ORB Straight
339911 1 • O-Ring, -10 ORFS
339899 1 • O-Ring, -10 ORB
3 4327706 1 Tube, Reel Valve to Right Rear Reel
4 4328570 1 Hose, Right Rear Reel Pressure
5 340070 4 Fitting, -10 ORFS x -10 ORB 90°
339911 1 • O-Ring, -10 ORFS
339899 1 • O-Ring, -10 ORB
6 4312506 2 Motor, 5” Reel Used on LF550/557, See 54.1
6 4311048 2 Motor, 7” Reel Used on LF570/577, See 55.1
7 4328570 1 Hose, Right Rear Reel Return
8 4327477 1 Tube, Right Reel to Left Reel
9 4328570 1 Hose, Left Rear Reel Pressure
10 4328570 1 Hose, Left Rear Reel Return
11 4327746 1 Tube, Left Rear Reel to Reel Valve
12 340193 2 Fitting, -10 ORFS 45° Bulkhead
339911 2 • O-Ring, -10 ORFS
13 340241 2 Fitting, -10 ORFS Straight Bulkhead
339911 2 • O-Ring, -10 ORFS
14 339963 4 Nut, -10 ORFS (7/8-14) Bulkhead
15 4113601 1 Tube, Return Manifold See 25.1
339909 1 • O-Ring, -6 ORFS
16 340026 2 Fitting, -6 ORFS x -6 ORB 45°
339909 1 • O-Ring, -6 ORFS
339897 1 • O-Ring, -6 ORB
17 4328573 1 Hose, Left Rear Reel Drain
18 340239 2 Fitting, -6 ORFS Straight Bulkhead
19 339961 2 Nut, -6 ORFS (9/16-18) Bulkhead
20 4327478 1 Tube, Left Rear Reel Drain
21 4328573 1 Hose, Right Rear Reel Drain
22 4327469 1 Tube, Right Rear Reel Drain
