75
> Change from previous revision
LIGHTWEIGHT FAIRWAY MOWER
Item Part No. Qty. Description Serial Numbers/Notes
1
4195082 1 Valve, Reel See 24.1
2 339989 2 Fitting, -10 ORFS x -10 ORB Straight
339911 1 • O-Ring, -10 ORFS
339899 1 • O-Ring, -10 ORB
3 340070 4 Fitting, -10 ORFS x -10 ORB 90°
339911 1 • O-Ring, -10 ORFS
339899 1 • O-Ring, -10 ORB
4 4327466 1 Tube, Reel Valve to Left Wing Reel Reel Valve Port LA
▲ 5 4328571 1 Hose, Left Wing Reel Pressure Hose in bundle with blue stripe
6 4312506 2 Motor, 5” Reel Used on LF550/557, See 54.1
6 4311048 2 Motor, 7” Reel Used on LF570/577, See 55.1
● 7 4328571 1 Hose, Right Wing Reel Pressure Hose in bundle with blue stripe
8 340169 2 Fitting, -10 ORFS 90° Bulkhead
339911 2 • O-Ring, -10 ORFS
9 339963 4 Nut, -10 ORFS (7/8-14) Bulkhead
▲ 10 4328577 1 Hose, Left Wing Reel Return
11 4327468 1 Tube, Left Wing Reel to Reel Valve Reel Valve Port LB
12 340241 2 Fitting, -10 ORFS Straight Bulkhead
339911 2 • O-Ring, -10 ORFS
● 13 4328577 1 Hose, Right Wing Reel Return
14 4326927 1 Tube, Right Wing Reel to Reel Valve Reel Valve Port RB
15 339977 2 Fitting, -6 ORFS x -4 ORB Straight
339909 1 • O-Ring, -6 ORFS
339896 1 • O-Ring, -4 ORB
▲ 16 4328574 1 Hose, Left Wing Reel Drain
17 340119 2 Fitting, -6 ORFS Straight Run Tee See 35.1
339909 2 • O-Ring, -6 ORFS
● 18 4328574 1 Hose, Right Wing Reel Drain
19 400356 4 Clamp, 1-11/16” See 43.1
20 473142 2 Cable Tie, 3/16 x 16”
21 4326926 1 Tube, Reel Valve to Right Wing Reel Reel Valve Port RA
22 4256474 2 Reducer, -6 ORB to -4 ORB
339909 1 • O-Ring, -6 ORFS
▲ Included in Left Wing Hose Bundle 4328826
● Included in Right Wing Hose Bundle 4328826
To Next Page
