77
> Change from previous revision
LIGHTWEIGHT FAIRWAY MOWER
Item Part No. Qty. Description Serial Numbers/Notes
1
4195081 1 Lift Valve 5 Gang Option, See 24.1
1 4195083 1 Lift Valve 7 Gang Option,
2 339979 6 Fitting, -6 ORFS x -6 ORB Straight
339909 1 • O-Ring, -6 ORFS
339897 1 • O-Ring, -6 ORB
3 4287312 6 Disk, 0.040” Orifice
4 4240022 1 Hose, Lift Valve to Right Cylinder Lift Valve Port 1, Cylinder Rod Port
5 4240182 1 Hose, Lift Valve to Center Cylinder Lift Valve Port 2, Cylinder Rod Port
6 4240183 1 Hose, Lift Valve to Left Cylinder Lift Valve Port 3, Cylinder Rod Port
7 340061 6 Fitting, -6 ORFS x -6 ORB 90°
339909 1 • O-Ring, -6 ORFS
339897 1 • O-Ring, -6 ORB
8 4193221 2 Cylinder, Lift See 42.1
9 4193220 1 Cylinder, Lift See 42.1
10 4240023 1 Hose, Right Cylinder to Lift Valve Lift Valve Port 8, Cylinder Base Port
11 4240024 1 Hose, Center Cylinder to Lift Valve Lift Valve Port 9, Cylinder Base Port
12 4240025 1 Hose, Left Cylinder to Lift Valve Lift Valve Port 10, Cylinder Base Port
13 108138-04 2 Clamp, Double Tube
14 409811 2 Screw, 5/16-18 x 5/8” Thread Cutting
15 473142 1 Cable Tie, 3/16 x 14” Right Cylinder Hoses
16 339909 6 O-Ring, -6 ORFS
To Next Page
