85
> Change from previous revision
LIGHTWEIGHT FAIRWAY MOWER
Item Part No. Qty. Description Serial Numbers/Notes
1
4300317 1 Gear Pump, Three Section 5 Gang Option, See 21.1
1
4300318 1 Gear Pump, Four Section 7 Gang Option, See 21.1
2 340274 1 Tee, 8-10-8 Straight Run
339910 2 • O-Ring, -8 ORFS
339898 1 • O-Ring, -10 ORB
3 364945 1 Fitting, -8 ORFS Diagnostic
4 363030 1 Dust Cover
5 1003334 1 Hose, Pump to Steering Valve Steering Valve Port P
6 4212981 1 Steering Valve See 12.1
339908 2 • O-Ring, -4 ORFS
339909 1 • O-Ring, -6 ORFS
7 4215600 1 Hose, Steering Valve to Outside Tube Steering Valve Port L
339909 1 • O-Ring, -6 ORFS
8 4327629 1 Tube, Outside (Left Turn) Steering
339909 1 • O-Ring, -6 ORFS
9 4326587 1 Hose, Outside Tube to Cylinder
339909 1 • O-Ring, -6 ORFS
10 4271774 1 Cylinder, Steering See 10.1 or 11.1
4276851 1 • Seal Kit
339908 2 • O-Ring, -4 ORFS
11 4326586 1 Hose, Cylinder to Inside Hose
339909 1 • O-Ring, -6 ORFS
12 4327480 1 Tube, Inside (Right Turn) Steering
339908 1 • O-Ring, -4 ORFS
13 4215600 1 Hose, Inside Tube to Steering Valve
339909 1 • O-Ring, -6 ORFS
14 364221 3 Clamp, Double Tube
15 445770 3 Nut, 1/4-20 Nylon Insert Hex
16 4215080 1 Tube, Steering Tube to Brake Valve Brake Valve Port ST, See 31.1
17 4326588 1 Tube, Outside Connecting
339909 1 • O-Ring, -6 ORFS
18 4326589 1 Tube, Inside Connecting
339909 2 • O-Ring, -6 ORFS
