LIGHTWEIGHT FAIRWAY MOWER
Item Part No. Qty. Description Serial Numbers/Notes
1
4326426 1 Harness, Main Wire See 8.1
2 4293091 1 • Card, 100µF 16V Capacitor REFERENCE C1, See 62.1
3 2811608 1 • Cap, Connector
4 5003280 1 • 10 Amp Fuse, Engine Controller REFERENCE F1, See 62.1
5 5003283 1 • 25 Amp Fuse, Main Relay REFERENCE F2, See 62.1
6 5003278 1 • 5 Amp Fuse, Start Signal REFERENCE F3, See 62.1
7 5003278 1 • 5 Amp Fuse, Diagmaster REFERENCE F4, See 62.1
8 4312246 1 • 15 Amp Fuse, Air Ride Seat REFERENCE F5, See 62.1
9 4312213 1 • 10 Amp Fuse, LDU REFERENCE F6, See 62.1
10 1 • 2 Amp Fuse, Cruise REFERENCE F10, See 62.1
11 4358787 1 Controller, Mower (MCU) REFERENCE U18, See 62.1
12 5003282 1 • 20 Amp Fuse, Lights REFERENCE F7, See 62.1
13 5003282 1 • 20 Amp Fuse, 12V Output REFERENCE F8, See 62.1
14 452398 2 Screw, M10-1.5 x 20 mm Hex Flange
15 361439 1 Circuit Breaker, 50 Amp 12V REFERENCE CB1, See 62.1
16 800296 2/4 Screw, #10-24 x 3/4” Pan Head LF550 & LF570/LF557 & LF577
◆ 17 1 Controller, Engine (ECU) REFERENCE U1, See 62.1
18 445795 4 Nut, 5/16-18 Spiralock Flange
19 4329528 1 Controller, Wing Module LF557 and LF577 Option Only
20 303952 2 Flat Washer, #10 LF557 and LF577 Option Only
21 4122840 2 Headlight REFERENCE L1 and L2, See 62.1
4123183 1 • Bulb
22 4234620 4 Tie Strap, Push Nut Mount
23 N/S 1 Battery REFERENCE B1, See 62.1
24 4301101 1 Cable, Positive Battery Battery to Starter
25 4301100 1 Cable, Negative Battery Battery to Engine Block
26 4193880 1 Relay, Main REFERENCE CR1, See 62.1
27 4193880 1 Relay, Glow Plug REFERENCE CR2, See 62.1
28 4193880 1 Relay, Starter REFERENCE CR3, See 62.1
29 4271132 1 Cable, Engine Ground
30 365979 1 Screw, M12-1.25 x 25 mm Hex Head
31 446154 1 Lockwasher, 1/2 Heavy
32 453017 1 Flat Washer, 1/2
33 4136366 4 Spacer, Controller
34 4167640 3 Cable Tie, Fir Tree
35 4257272 3 Panel Mount, Fir Tree
36 446116 8/10 Lockwasher, #10 LF550 & LF570/LF557 & LF577
37 444310 8/10 Nut, #10-24 Hex LF550 & LF570/LF557 & LF577
38 4343207 1 Bracket, Harness Support
39 4301153 1 Harness, Wing Mower LF557 and LF577 Option Only
40 450192 2 Screw, M8-1.25 x 16 mm Battery Terminal Screws (Not Shown)
◆ Contact customer service with Engine Model and Engine Serial Number
