95
> Change from previous revision
LIGHTWEIGHT FAIRWAY MOWER
Item Part No. Qty. Description Serial Numbers/Notes
1
REF 1 Inner Reel See 47.1
2 1002224 2 Zerk Bolt
3 1000770 1 22” x 2” Ø Rear Roller Standard Rear Roller. See 51.1
3 5003687 1 20” x 2-1/2” Ø Rear Roller Optional Rear Roller
3 1003728 1 22” x 2-1/2” Ø Rear Roller Optional Rear Roller
3 1002446 1 24” x 2-1/2” Ø Rear Roller Optional Rear Roller
4 2810043 1 Shield, Grass
5 4181863 1 Decal, Read Manual for Service
6 4127335 2 Decal, Danger
7 400264 2 Screw, 3/8-16 x 1-1/4” Hex Head
8 403782 2 Screw, 1/4-20 x 3/4” Truss Head
9 453023 2 Flat Washer, 1/4
10 446130 4 Lockwasher, 1/4 Heavy
11 443102 4 Nut, 1/4-20 Hex
12 3008438 1 Bracket, Left SIde Front Roller
13 3008439 1 Bracket, Right Side Front Roller
14 441674 2 Carriage Bolt, 5/16-18 x 1-3/4”
15 445795 4 Nut, 5/16-18 Spiralock Flange
16 343616 2 Stud, Front Roller Adjuster
17 3005692 2 Knob, Front Roller Adjuster
18 367164 1 Spacer
19 453011 3 Flat Washer, 3/8
20 446142 3 Lockwasher, 3/8 Heavy
21 400294 1 Screw, 3/8-24 x 1” Hex Head
22 REF 1 Front Roller Not included with reel.
23 352737 2 Set Screw, 1/4-20 x 7/8” Grade 8
24 345510 2 Spacer, Lift Yoke
25 2000065 1 Casting, Counterweight
26 400110 2 Screw, 1/4-20 x 7/8” Hex Head
27 338735 1 Scraper, 22” Rear Roller
28 400184 2 Screw, 5/16-18 x 3/4” Hex Head
29 403770 2 Screw, 5/16-18 x 3/4” Hex Flange Front Wing Reels Only
30 445795 2 Nut, 5/16-18 Spiralock Flange Front Wing Reels Only
31 3008199 1 Skid, Left Hand Reel Right Front Reel Only
32 3008200 1 Skid, Right Hand Reel Left Front Reel Only
To Next Page
