J&M 620 - Hitch and Jack Assembly; Hitch and Jack Component Identification

22
Description Part No.
1 1-1/4” Pin Adapter for Hitch (1 Adapter) JM0019032
2 1-1/2” Pin Adapter for Hitch (1 Adapter) JM0014203
3 Bolt On Spade Hitch with 2-1/4” Hourglass Pin Hole JM0017978
4 Tang with 4 Bolts (2-1/4” Hourglass Pin Hole) JM0017976
5 3/4”-16 x 3” Gr8 YZ Fine Thread Hex Bolt JM0002107
6 1”-8 x 7-1/2” Gr8 YZ Hex Bolt JM0017944
7 2-1/2” x 13-1/4” Pin and Collar (212PC) JM0018259
8 2-1/2” Hitch Spool Plate (HSPS-1) JM0018195
9 1”-8 Gr2 Z Centerlock Hex Nut JM0002149
10 2-1/2” Hitch Spindle Collar JM0018219
11 1”-8 x 4-1/2” Gr5 Z Hex Bolt JM0016687
12 3/4”-16 x 3” Gr8 Z Hex Bolt JM0018542
13 Hitch Block Reducer (Sleeve) (2-7/8” to 2-1/2”) JM0018258
14 Jack Stand Assembly including 5/8” Pin (7,000 lbs. Lift Capacity) (TWL-200) JM0010191
15 Clevis Bolt-On Hitch Assembly (2-1/4” Hourglass Pin Hole) JM0018191
16 30k Lb Safety Chain JM0031890
Hitch and Jack Assembly
14
15
5
9
11
12
10
8
7
4
13
9
3
2
1
6
16
