25
Flow Control Spout
321 4
5 6 7
98
Description Part No.
1 14” Flow Control Spout Housing (FSH-14) JM0024441
2 14” Bae Plate (BP-14) JM0012702
3 14” Hinge Plate (HP-14) JM0024445
4 1/2”-13 x 2” Gr5 Z Hex Bolt JM0001593
5 5/32” x 1-1/2” Cotter Pin JM0014348
6 1/2” x 1-3/4” Clevis Pin, Usable Length 1-1/2” JM0018264
7 1/2”-13 Gr2 Z Centerlock Hex Nut JM0001511
8 1/4”-20 x 3/4” Gr5 Z Hex Bolt JM0001507
9 1/4”-20 Gr2 Z Centerlock Hex Nut JM0001505
To Next Page
