Section 3. Installation Instructions
Before you begin your installation, please check that you have the right tools and a suitable location to install the
power pack and cell. Please ensure that you have read and understood the Important Safety Instructions section.
3.1 Materials and Tools
Installation Materials Furnished Tools Needed for Installation
• PipeSpacer-for1½in.(40mm)pipe
• HoleSaw
• ScrewSet(includeswallplugs)
• InstallationandOperationManual
• CordlessDrill(orPowerDrill)
• 15/64in.(6mm)HammerDrillBit(onlynecessarytodrillinto
brickorconcrete)
• PencilorMarkingPen
• PhillipsHeadScrewdriverorPhillipsHeadDrillBit
WARNING
EQUIPMENT UNDER PRESSURE: AlwaysturnpumpoffpriortoinstallingorservicingtheJandy®AquaPure®
Eichlorinegeneratingdevice.Yourpump/ltersystemisoperatedunderpressureandthepressuremustbe
releasedbeforeyoubeginwork.Pleaseseeyourpump/lterowner’smanualforfurtherinstructions.
WARNING
TheJandyAquaPureEichlorinegeneratingdevicemustbeinstalled
horizontallywiththecellabovethepipetoavoidbuildupofammable
gaseswhichcanresultinFIREOREXPLOSION.
Figure 3. Installation Requirements
15 ft. (4.6 m) MAX
Cell
Power
Pack
1 ⅓ ft. (0.38m) MIN
3.2 Installation Requirements
WARNING
FOR YOUR SAFETY: Thisproductmustbeinstalledandservicedbyaprofessionalpool/spaservicetechnician.
Theproceduresinthismanualmustbefollowedexactly.Failuretofollowwarningnoticesandinstructionsmay
resultinpropertydamage,seriousinjury,ordeath.Improperinstallationand/oroperationwillvoidthewarranty.
The installation requirements for the Jandy AquaPure Ei chlorine
generating device are as follows:
•
The power pack must be be installed at least 5 ft. (1.5 m) vertically off
the ground.
• IntheUS,the power pack must be be installed at least 5 ft. (1.5 m) from
the inside wall of your swimming pool or spa; in Canada, the power
pack must be be installed at least 10 ft. (3 m) from the inside wall of your
swimming pool or spa.
• Thecellmustbeinstalledona1⅓ft.(0.4m)horizontallength
ofpipeaftertheheaters,pumps,andlters,asthelastpieceof
equipment in the circulation plumbing system just before the pool (see
Figure 3).
• Thecellmustbeinstallednomorethan15ft.(4.6m) from the power
pack (see Figure 3).
