3.7 Bypass Plumbing Instructions
Themaximumowrateforthecellis92gpm.Ifowrateexceeds92gpm,thecellMUSTbeplumbedonby-pass
(seeFigure22).Acontrolvalvemustbeinstalledtoregulatetheowthroughthecell.Itcanbeinstalledontheinletside
ofthecellorbetweentheinletanddischargesideofthebypasspiping.Theproperowwillbeachievedbyadjustingthe
handle of the valve until the red “No Flow” light has turned off and all large air bubbles are cleared from the cell.
Do not install
past 45 degrees
Figure 22. Example of Bypass Installation
Figure 23. Example of Alternative Installation
3.8 Alternative Installation (When Pipe is Obstructed)
Iftheonlysuitablelengthofpipeisobstructed,suchasonamultiportvalveoftenfoundonasandlter,itis
acceptableto‘lean’thecelloveruptoamaximumof45degrees(seeFigure23).Markthefeederholesinthesame
angle that the cell will be leaning to ensure that you drill in the right position.
The cell must be installed as the last piece of
equipment in the circulation plumbing system
just before the pool
Cell
Heater
Pump
Power Pack
Filter
Pool Intake
Spa Intake
Spa ReturnPool Return
To common
power source
Control Valve Installation Options
Installontheinletside
ofthevessel
Installbetweentheinlet
anddischargesideof
bypassplumbing
Water Flow
