Page 19
ENGLISH
Jandy
®
Pro Series VS FloPro™ Series Variable-Speed Pump
|
Installation & Operation Manual
Symptom Possible Cause/Solution
Pump will not start. No power to pump.
Make sure pump is properly connected to high voltage. See Section 3.2, Electrical
Installation, in this manual.
Improper low-voltage wiring.
Check low-voltage wiring between pump and controller. Correct if necessary. See
Section 3.2, Electrical Installation, in this manual.
Improper pump address setting.
Make sure that pump dip switches 3 and 4 are set properly for the installation. Both
should be OFF for use with Variable-Speed Controller or set to the proper address
when connected to an AquaLink
®
RS controller, an AquaLink
PDA, or an AquaLink
Z4. See Section 3.3, VS-FHP Pump Dip Switch Settings, in this manual. Note: VS-
FHP1.0 should always have dip switch setting 5 set to ON for both controllers.
Fault condition exists.
View fault message on controller and correct fault before proceeding. If unsure how
to correct fault, contact Zodiac
®
Technical Support at 800.822.7933. In Canada, call
1-888-647-4004
Variable-Speed Controller
LCD is not displaying
information
or
pump LEDs are not
illuminated.
Incorrect dip switch setting.
Make sure pump dip switches 1 and 2 are both ON if the controller is the JEP-R and
both are OFF if the controller is a PDA, AquaLink RS, or AquaLink Z4. See Section
3.3, VS-FHP Pump Dip Switch Settings, in this manual. Note: VS-FHP1.0 should
always have dip switch setting 5 set to ON for both controllers.
Improper low-voltage wiring.
Check low-voltage wiring between pump and controller. Correct if necessary. See
Section 3.2, Electrical Installation, in this manual.
Controller displays “Pump
not connected”.
Improper low-voltage wiring.
Check low-voltage wiring between pump and controller. Correct if necessary. See
Section 3.2, Electrical Installation, in this manual.
Improper pump address set.
Ensure pump dip switches 3 and 4 are set properly for the installation. Both should
be OFF for use with Variable-Speed Controller or set to the proper address when
connected to an AquaLink
RS controller, an AquaLink PDA, or an AquaLink Z4. See
Section 3.3, VS-FHP Pump Dip Switch Settings, in this manual. Note: VS-FHP 1.0
should always have dip switch setting 5 set to ON for both controllers.
Fault message appears on
controller display.
Fault condition exists.
View fault message on controller and correct fault before proceeding. If unsure how
to correct fault, contact Zodiac Technical Support at 800.822.7933. In Canada, call
1-888-647-4004
