ENGLISH
Jandy
®
Pro Series VS FloPro™ Series Variable-Speed Pump
|
Installation & Operation Manual
Section 7. Product Specications and Technical Data
7.1 Replacement Parts List and Exploded View
To order or purchase parts for Zodiac
®
pumps, contact your nearest Zodiac dealer. If the Zodiac dealer cannot
supply you with what you need, contact Zodiac Technical Support at 1.800.822.7933, or send an e-mail message to
productsupport@zodiac.com. In Canada, 1-888-647-4004, customerservice PSC@zodiac.com
Key
No. Description Order Part No.
1 Motor, Drive, VS-FHP2.0 R0562201
1 Motor, Drive, VS-FHP1.0 R0571000
2 Backplate, (Backplate w/Hardware, Backplate O-ring & Mechanical Seal) R0479500
3 Impeller, (Impeller, Screw w/O-ring), VS-FHP2.0 R0479605
3 Impeller, (Impeller, Screw w/O-ring), VS-FHP1.0 R0479603
4 Diffuser, (Diffuser w/O-ring, Hardware & Backplate O-ring) R0479701
5 Mechanical Seal, Carbon and Ceramic (1 Set) R0479400
6 Pump Body, (Body and Backplate O-ring) R0479800
7 Motor Mounting Foot R0479900
8 Lid w/Locking Ring, (Lid w/Locking Ring & Lid O-ring) R0480000
9 Pump Debris Filter Basket R0480100
10 Drain Plug w/ O-ring (Set of 2) R0446000
11 Tail Piece, O-ring & Union Nut (Set of 2) R0327301
12 Lid O-ring R0480200
13 Backplate O-ring R0480300
14 Tailpiece O-ring (Set of 2) R0337601
15 Diffuser/Impeller Hardware (Diffuser O-ring, Screws (2), Self Sealing Screw) R0480400
16 Backplate Hardware (Backplate Hardware & Backplate O-ring) R0480500
17 Motor Hardware Kit R0446700
18 Pump Base Kit R0486700
19 Cover Fan, GEN II Replacement Kit (Hardware, Cover) R0562400
20 Hardware Speed Drive, GEN II R0562500
21 Connector, Speed Drive, VS-FHP Pump (4-Pin Connector) R0660900
22 Cable, RS485, Replacement Kit R0535100
23 Screw w/O-Ring R0515400
24 Cover, Large, Speed Drive w/Gasket, GEN II R0562300
25 Base Spacer, FHP, VS-FHP, Replacement Kit R0546400
26 Data Cable, Feed Thru R0501100
27 User Interface Kit, Variable-Speed Pumps JEP-R
28 Cover, Controller, VS-FHP 1.0 R0571500
29 Fan Cover, VS-FHP1.0 R0571300
30 Access Cover, VS-FHP1.0 R0571400
31 User Interface Screws, VS-FHP1.0 R0571600
32 Conduit Fitting, 1/2 NPT, VS-FHP1.0 R0501101
33 Rear Access Cover Screw, VS-FHP1.0 R0587600

Jandy VS FloPro Series Specifications

General

Motor Type	Variable Speed
Voltage	115/230V
Control Interface	Digital
Motor Frame	56J
Plumbing Size	2 inches
