Zodiac Pool Systems, Inc.
2620 Commerce Way, Vista, CA 92081
1.800.822.7933 | www.ZodiacPoolSystems.com
Zodiac Pool Systems Canada, Inc.
2115 South Service Road West, Unit 3 Oakville (ON) L6L 5W2
+ 1 (888) 647-4004 | www.ZodiacPoolSystems.ca
ZODIAC
®
is a registered trademark of Zodiac International, S.A.S.U., used under license.
All trademarks referenced herein are the property of their respective owners.
©2013 Zodiac Pool Systems, Inc. H0420400 Rev C
ETL LISTED
CONFORMS TO
UL STD 1081
Certified to
CAN/CSA C22.2
No. 108
Certied to
NSF/ANSI Standard 50
Figure 18. VS-FHP1.0 Dimensions
10 7/8"
276 mm
6 1/2"
165 mm
12 3/4"
324 mm
7 3/4"
197 mm
10"
254 mm
11 1/8"
283 mm
27 3/16"
691 mm
Front Edge of Union
to Center of Bolt Holes
Bolt Holes,
Figure 19. VS-FHP2.0 Dimensions
641 mm
25 ¼”
283 mm
11 ⅛”
254 mm
10”
197 mm
7 ¾”
324 mm
12 ¾”
165 mm
6 ½”
Bolt Holes,
Center to Center
276 mm
10 ⅞”
Front Edge of Union
to Center of Bolt Holes
7.4.2 Dimensions
NOTE
When installing a pump, leave a minimum of two (2) feet (30 cm) of clearance above the pump for removal of the strainer basket.
