janitza UMG 604 - Page 39

39
UMG 604
16
17
Digital
Output 1
K2 K1
+
-
24V
DC
18
Digital
Output 2
16
17
Digital
Output 1
K2 K1
~
24V
AC
18
Digital
Output 2
~
Fig. 39.2 Connection of direct current relays
to the digital outputs.
Fig. 39.1 Connection of alternating voltage
relays to the digital outputs.
UMG604
Digital outputs
UMG604
Digital outputs
