66
17: Coasting stop
When this terminal is valid, inverter coasting to stop.
18. Fault reset
Reset the inverter when alarm occurs, this terminal function is sameto that of
the RESET key on the Keypad.
19. PID function enable
When this contact closes, PID function is enabled. When P601 is set as 2, PID is
invalid when this contact is disconnected.
20. PLC function enable
When this contact closes, PLC function starts up, and corresponding PLC
function opens.
21. Timer 1 starts up
22. Timer 2 starts up
When this contact closes, timer starts up and begins timing, when the timer
reaches set value, corresponding multifunction output contacting action.
23. Counter pulse input
This terminal may accept pulse signals of no more than 250 Hz.
24. Counter resetting
The counted values may be reset and cleared through this terminal.
19. PLC memory removal
In the running process of PLC program, owing to fault or stopping, inverter will
record status of the program automatically, after the fault is cured and the
inverter is switched on again, the inverter will continue running according to the
program，when memory removal is valid, program may be reset, and inverter
operates from the beginning.
6
Chapter 6 Description of parameter setting
FC100 Series User Manaul
