Janson Controls FC100-2S-1.5G User Manual

17
3.4 Main Circuit Wiring
Single phase models input from R/L1, S/L2
AC line input terminals
grounding
UP/DOWN
Function
Display key
Data
Confirmation key
RUN/STOP
RS485
communication
port
Grounding
Motor connections U/T1, V/T2, W/T3
Motor capacity
and input power
Frequency
setting knob
LED display
The signal selection
for AVI to input
DC0-+10V
or 4-20 mA
U/T1 V/T2 W/T3
R/L1 S/L2
T/L3
Control Terminal
Torque: 4Kgf-cm (3 in-lbf)
Wire: 22-24 AWG
Power Terminal
Torque: 5Kgf-cm (4.33 in-lbf)
Wire: 12-20 AWG
3
ENTER
DISP
FC100 Series User Manaul
Chapter 3 Wire diagram and terminal explanation
