10 - Bit character box (For ASCII)
Data pattern: 8N1 For ASCII
2.. Character structure
Start bit 0 1 2 3 4 5 6 7 Stop bit
8-Data bits Character string
10-bits Characte r box
10 - Bit character box (For RTU) Data pattern: 8N1 For RTU
Start bit 0 1 2 3 4 5 6 7 Stop bit
8-Data bits Character string
10-bits Characte r box
Data pattern: 801 For ASCI I
Start bit 0 1 2 3 4 5 6 7
Stop bit
8-Data bits Character string
11-bits Characte r box
Odd parity
Data pattern: 8E1 For ASCII
Start bit 0 1 2 3 4 5 6 7
Stop bit
8-Data bits Character string
11-bits Characte r box
ever parity
