Jasco P-1010 User Manual


7
Name
Function
 “Power” switch
 Frequency
change switch
 Ground terminal
 “AC Input” connector
 “FUSE”
 “iRM PS” connector
 “Serial” connector
 “AUX1”, “AUX2”
connector
 “Analog Out” terminal
 “Temp. Control”
connector
11
“LC Out” terminal
Power switch
Matches to the frequency of the power line.
Be sure to ground this terminal.
Connects the power cable.
The specified fuse for the voltage is contained here. Be
sure to match the voltage of the power source being
used.
Enables power to be supplied to the intelligent remote
module (iRM). Connector for connecting cable.
Connected to the ²COM 1 ² connector on PC.
Connector for connecting the quick flow sampler
(optional).
Outputs a 3 digit angle component corresponding to the
set measurement values in units of mV during normal
measurement.
Connector for the optional temperature controller.
Outputs a direct current voltage using 0.1°/V in LC
mode.
