Jasco P-1010 User Manual


11
(3) Install the cell holder temperature sensor.
1) Insert the sensor from above the temperature sensor fixture.
Note: Here, see to it that no stress is applied to the signal wire of the temperature
sensor.
3.3 Consumables
Table 3.1 Consumables list
Parts No.
Description
Specification
5330 - 0080
5330 - 0006
5330 - 0099
5332 - 0001
1009 - 0042A
1009 - 0043A
1009 - 0044A
1009 - 0045A
1009 - 0059A
Sodium lamp
Mercury lamp
Halogen lamp
The glow discharge tube
Filter (589nm)
Filter (578nm)
Filter (546nm)
Filter (435nm)
Filter (365nm)
Na/10 Life: Approx. 800 hour
Hg/10 Life: Approx. 800 hour
64258(P) Life: Approx. 2000 hour
FG-4P Life: Approx. 6000 time
589nm/12nm Life: Approx. 1year
578nm/12nm Life: Approx. 1year
546nm/12nm Life: Approx. 1year
435nm/12nm Life: Approx. 1year
365nm/12nm Life: Approx. 1year
