Jasco P-1010 User Manual



ii
(2) Warning Label
Warning labels are attached at several locations on this instrument. Do not remove,
deface or damage the warning labels. If a warning label peels off the instrument or
becomes illegible, contact your local JASCO distributor for a replacement label. Be
sure to indicate the part No. on the label.
1) Warning for FUSE (

on Figure 1, 2 or 3)
WARNING
FOR CONTINUED
PROTECTION AGAINST
RISK OF FIRE, REPLACE
ONLY WITH FUSE OF THE
SPECIFIED TYPE AND
CURRENT RATINGS.
Part No.：0822-0102A
2) Warning for GROUND (

on Figure 1, 2 or 3)
WARNING
MAINS PLUG GROUND
PIN OR GROUND
TERMINAL MUST BE
CONNECTED TO
GROUND.
Part No.：0822-0104A
Power
On
Off
AC Input
T3.15A(100-120V )
T2A (200-240V)
FUS E
Serial
iRM PS
AUX1
AUX2
LC Out
Temp. Control
Analog
Out
GND
GND
1
2
Figure 1 Rear panel of P-1010
Only use fuses of the designated rating to protect
both operator and instrument from fire and other
hazards. The warning labels that pertain to fuse
ratings are located on the back panel of the
instrument .
Be sure to ground the mains plug ground pin.
Otherwise, ground the ground terminal on the
back panel of the instrument.
