56
Touch pad is locked
Touch pad is active
Jacks are moving
Low battery
The OneControl touch screen or Leveling App will show the specic error.
Refer to troubleshooting section of the LCI Ground Control 3.0 manual to clear the error.
1. Before unhitching from the tow vehicle, ensure the RV is parked on a level surface and
tires are chocked.
2. Extend the inner legs of both landing gear (front jacks) to within 4”- 5” of the ground
by pulling on the quick release pins.
3. Turn on the touchpad by pressing both arrow buttons simultaneously. LED illuminates
solid green.
4. Press the UP arrow button to extend the front jacks to lift the front of the RV taking
weight o the hitch.
5. Uncouple the RV connection to the tow vehicle. Pull tow vehicle away.
1. Turn on the touchpad.
2. LED will light up solid green.
3. Select AUTO LEVEL and the auto leveling process begins. Front of the RV will seek
a position near level. Rear jacks will be grounded (on 4 point system). Side to side
leveling will begin.
4. Each jack will perform a nal grounding touch.
When the leveling cycle has started, it is important there
is no movement inside the RV until leveling is complete. Failure to
remain still during leveling could affect the performance of the level-
ing system.
On a 6 point system the 2 middle jacks will be grounded to
stabilize the trailer. The 2 middle jacks do not level the RV
Pressing both the arrow buttons simultaneously turns on
the touchpad. Touchpad will time out after 7 minutes of non-use.
