10. Install the transit bars (if so equipped)
to the slideout room and take the unit to
an authorized dealer for service.
Refer to the Power Gear® Electric Slideout
Operation Manual for detailed operation,
safety and troubleshooting information.
The Power Gear® Slim Rack slideout is typically used for
slideouts 144” long and longer.
It is operated by a 12VDC electric motor.
The system is equipped with a manual override al-
lowing the room to be extended / retracted in the
event of a power loss.
The system has a controller (Fig 1) with program-
mable stops that stop the motor when the room is
fully extended or retracted.
The controller has the ability to detect faults for easier troubleshooting.
A wall mounted touchpad allows room movement and provides end user feedback.
The slideout will not function until the stops are properly set or
faults are cleared.
indicates room movement.
with the system.
(Refer to the Fault Diagnostics / Troubleshooting).
To ensure ample voltage is being supplied to the slideout sys-
tem motor, power should be supplied from one of the follow-
ing sources:
Attach the RV to shore power.Have the mo-
torhome engine running.
Turn on the generator.
1. Engine or generator must be running, or plugged into
shore power.
2. Transmission must be in park or neutral (if applicable).
3. Set the parking brake and level the unit.
4. Remove transit bars (if so equipped) if extending the
room; install if retracting.
5. Turn the on/o switch or key.
