82
Code
1 Major
Stops not
programmed
-Stops have not been
set
-Stops were cleared
-Stops were improp-
erly set
Steps need to be programmed
by an authorized service
facility.
2 Minor System Fault
-Obstruction present
-Excessive system
drag
Run room in opposite direc-
tion. If it continues to move
in the opposite direction,
remove obstruction, exces-
sive weight in room or repair
of damaged component. If
room stops moving in op-
posite direction, observe fault
code and refer to this chart
4 Major
Excessive
Battery Volt-
age
-Bad or loose con-
nection
-Defective harness
-Open or shorted
motor
-Check all connections at
control box and motor
-Check the harness for bro-
ken wires.
-Put 12.0 VDC direct to
the motor. If it does not run
replace the motor.
6 Minor
Supply voltage to
control box is 17 0 V
DC or greater
Check 2-pin power connector
at control box. If the voltage
is 17. VDC or higher, contact
O.E.M for power and ground
supplies
Park brake LED ashing
-Parking brake not set
(if applicable)
-Ground signal lost at
park brake control
-Set parking brake (if ap-
plicable)
-Check for continuity to
ground on wire plugged
into park brake connector at
control box
Low voltage LED ashing
Incoming violated to
control box is below
12.0 VDC
Check 2-pin power connec-
tor at control box. If voltage
is below 12.0 VDC contact
O.E.M for power and ground
supplies.
The Power Gear® slideout system requires very little maintenance. Read and follow these
procedures:
When the room is extended, visually inspect the slide rail assemblies. Check for
excess buildup of dirt or foreign material; remove any debris that may be present.
If the system squeaks or makes any noises, blow out any debris from the gear rack
arms and apply a dry lubricant to prevent and/or stop squeaking.
