Air Conditioning (cont’d)
No Air Conditioning
CHECK ACTION
1 Are the controls set correctly, i.e. air conditioning YES: Check 2
selected, thermostat switch set to coldest position NO: Reset controls and retest.
and blower switched on?
2 Is the air conditioning (evaporator) blower working? YES: Check 3.
NO: Check 4.
3 Is the compressor running (visual check of pulley/clutch)? YES: Check11.
NO: Check 7.
4 Is the air conditioning fuse (B8) blown? YES: Renew fuse and retest.
NO: Check 5.
5 Is there a 12V supply to the pressure switch harness? YES: Check 6.
Refer to Service Procedures - Pressure Switch Testing) NO: Check 9.
6 Does the compressor clutch engage with both YES: Check 7.
pressure switches bypassed? NO: Renew the compressor clutch and retest.
Refer to Service Procedures - Pressure Switch Testing)
7 Does the compressor clutch engage with YES: Renew high pressure switch and retest.
HP switch bypassed? NO: Check 8.
(Refer to Service Procedures - Pressure Switch Testing)
8 Does the compressor clutch engage with YES: Renew low pressure switch and retest.
LP switch bypassed? NO: Charge check required by refrigeration engineer.
(Refer to Service Procedures - Pressure Switch Testing)
9 Does the clutch engage with thermostat switch YES: Renew thermostat switch and retest.
bypassed? NO: Check all electrical connections.
10 Are blower switch and wiring OK? YES: Renew blower motor.
NO: Renew switch or wiring.
11 Is sight glass indication OK? YES: Check 12.
NO: Charge check required by refrigeration engineer.
12 Is condensor air flow blocked? YES: Clean condensor and radiator.
NO: Check 13.
13 Is evaporator air flow blocked? YES: Clean filter and, if necessary the evaporator.
NO: Call in refrigeration engineer.
