27 - 1
Section 3 Routine Maintenance
9803/7130
Section 3
27 - 1
Issue 1
Fluids, Lubricants, Capacities and Specifications
Note: New engines DO NOT require a running-in period. The engine/machine should be used in a normal work cycle
immediately; glazing of the piston cylinder bores, resulting in excessive oil consumption, could occur if the engine is gently
run-in. Under no circumstances should the engine be allowed to idle for extended periods; (e.g., warming up without load).
Engines of new machines are filled at the factory with JCB 10W/30 Multigrade oil. This oil should be drained after the first 100
hours operation and the engine filled with the appropriate recommended grade as shown in the lubrication chart. JCB 10W/30
Multigrade should also be used for the first 100 hours operation whenever a new or reconditioned engine is fitted to the
machine. After the first 100 hours operation, it is essential that the 10W/30 oil is replaced by the lubricant recommended
below.
ITEM CAPACITY FLUID/LUBRICANT INTERNATIONAL
Litres (UK Gal) SPECIFICATION
Fuel Tank 83.2 (18.3) Diesel Oil (See Types of Fuel) ASTM D975-66T Nos. 1D, 2D
Engine (Oil) 11.1 (2.5) JCB 15W/40 Multigrade SAE15W/40
-10 °C to 50 °C (14 °F to 122 °F) API CD/SE
JCB Super Universal Agricultural SAE10W/30
-15 °C to 30 °C (5 °F to 86 °F) API CD/SE
JCB Torque Converter Fluid SAE10W
-18 °C to 0 °C (0 °F to 32 °F) API CD/SE
Engine (Coolant) 12.0 (2.6) JCB Four Seasons Antifreeze ASTM D3306-74
& Summer Coolant/Water
(See Coolant Mixtures)
Syncro Shuttle 17.5 (3.8) JCB Special Transmission Fluid ESP-M2C 33G
Friction modified oils MUST NOT be used (eg. Dexron ATF type)
Axles
Housing (Front) 11 (2.4) JCB Special Gear Oil Plus API-GL4
Housing (Rear) 15.5 (3.4) Must be suitable for use with oil immersed brakes and limited slip
differentials (LSD).
Hubs (x4) 1.8 (0.4)
Hydraulic System ➀ 58 (12.75) JCB High Performance Hydraulic Oil ISO VG46
(tank capacity) (Above 38 °C, 100 °F)
JCB Special Hydraulic Fluid ISO VG32
(Below 38 °C, 100 °F)
Extending Dipper Waxoyl ➂
Stabiliser
Grease Points --- JCB HP Grease Lithium complex NLGI No. 2
consistency including
extreme pressure additives.
--- or JCB Special MPL-EP Grease ➁ Lithium based NLGI No. 2
consistency including
extreme pressure additives.
Electrical As a corrosion and moisture inhibitor all exposed connections should be
Connections coated with petrol jelly.
To Next Page
