AVO Test Kit
1 892/00283 Tool Kit Case
2 892/00298 Fluke Meter 85
3 892/00286 Surface Temperature Probe
4 892/00284 Venture Microtach Digital
Tachometer
5 892/00282 100 amp Shunt - open type
6 892/00285 Hydraulic Temperature Probe
Nylon Spatula -
general tool used for
smoothing sealants - also
used to re-install glass in rubber
glazing because metal tools will chip
the glass edge.
JCB part number - 892/00847
Service Tools(cont'd)
Section B - Body & Framework
4 - 4
Section 1 General Information
9803/7130
Section 1
4 - 4
Issue 1
S186470
Rubber Spacer Blocks - used to provide the correct
set clearance between glass edge
and cab frame.
JCB part number - 926/15500
(unit quantity = 500 off)
S186550
Section C - Electrics
993/85700 Battery Tester
S188230
Wiring Harness Repair Tools
1 892/00350 Butane Heater Assembly
2 892/00349 Crimp Tool
3 892/00351 Splice 0.5 - 1.5mm (Red)
4 892/00352 Splice 1.5 - 2.5mm (Blue)
5 892/00353 Splice 3.0 - 6.0mm (Yellow)
