5 - 11
Routine Maintenance (continued)
Cleaning the Oil Cooler
1 Park the machine on firm level ground. Engage the
parking brake and set the transmission to neutral. Stop
the engine and remove the starter key.
2 Remove the rear grille A to gain access to the cooler
matrix.
3 Brush off all debris from the cooler tubes and fins.
Make sure the loosened material is brushed out of the
cooler enclosure.
Section A Attachments
9803/7130
Section A
5 - 11
Issue 1
Airmaster Compressor
AA
