jcb Dumpster HTD5 User Manual

Section E - Hydraulics
Operation Description
Introduction to Hydraulic Schematic Symbols
E-5 E-5
9803-9570-4
Table 5. Energy Transmissions and Conditioning
Working line, return or feed
Pilot control
Drain lines
Flexible pipe
Line junction
Crossing lines
Air bleed
Line plugged, also pressure
test point
Line plugged with take off line
Quick release couplings -
connected
Quick release couplings -
disconnected
Reservoir - return line above
fluid level
Reservoir - return line below
fluid level
Header tank
Pressure sealed tank
Accumulator
Filter or strainer
Water trap
Cooler - with no indication of
coolant flow
Cooler - indicating direction
of coolant flow
Heater
