JCB EcoMAX Engine Installation Manual
Page 30 of 64 320/A9164-1 © JCB Power Systems Ltd.
10.4 Dipsticks
The dipstick is located on the left-hand side of the JCB EcoMAX engine, as shown in Figure
6. You must make sure that the dipstick is accessible to the equipment operator.
There are various dipstick options available. Please contact JCB Power Systems
Applications department for more information.
Figure 6: Location of a standard dipstick on an EcoMAX engine
10.5 Coolant
Use a minimum concentration of 30% antifreeze and corrosion inhibitor. You must choose
the concentration to give protection to the lowest expected ambient temperature. JCB Power
Systems Applications department for further information.
Table 3 shows the concentration you need to use depending on the ambient temperature.
The JCB EcoMAX engine coolant must be ethylene based to ASTM D6210. Please contact
JCB Power Systems Applications department for further information.
Table 3: Antifreeze concentration to protect at different ambient temperatures
