JCM G-556E - Pc Com. Timeout Time Programming; Modem Configuration String

74
9.54 PC COM. TIMEOUT TIME PROGRAMMING
P (97) X (A) SUB-TOTAL #
A = from 1 to 8 (default = 4) seconds
Note : this programming allows to define the timeout after which the ECR considers
conclused the operation in course, it's usefull above all in case of ECR connection
with a MODEM, this to have the possibility to manage eventual delays in the
communication due to telephone line problems or in case of connection to a PC not
dedicated to the ECR.
9.55 MODEM CONFIGURATION STRING
The Modem Hayes° can be set for their operation by a string sent from the Host on
the serial port ; G-556 can use a string of 28 Bytes that can contain the commands for, as
an example set the modem in modality of automatic answer or for the operation in MNP5°,
V42bis, etc... .
P (9) X/Time (***...*) X(by) SUB-TOTAL #
***...* = string for MODEM configure (Eg. ATS0=1 sets the modem in automatic
answer), the configuration string can contain Max. 28 characters, for
the commands see the modem configuration manual.
ENVOY OF COMMANDS STRING TO THE MODEM:
P (9) SUB-TOTAL
Or :
R Modem configuration envoy
Note : The modem it will maintain the setting until when it'll be turn OFF.
The first character of string cannot be a space.
KEY
KEY
only in case of of string shorter than 28 characters
KEY
KEY
